LAMMPS

What is LAMMPS

LAMMPS is a classical molecular dynamics code with a focus on materials modeling. It is an acronym for Large-scale Atomic/Molecular Massively Parallel Simulator.
LAMMPS features potentials for solid-state materials (metals, semiconductors), soft matter (biomolecules, polymers), and coarse-grained or mesoscopic systems. It can be used to model atoms or, more generically, as a parallel particle simulator at the atomic, meso, or continuum scale.
LAMMPS runs on single processors or in parallel using message-passing techniques and spatial decomposition of the simulation domain. Many of its models provide accelerated performance on CPUs and GPUs. The code is designed to be easily modified or extended with new functionality.

How to use LAMMPS on ENEAGRID/CRESCO infrastructure

In this page you can find the launching and submission syntax for LAMMPS codes on the  ENEAGRID/CRESCO infrastructure.  Please read the following documentation for running serial/parallel applications on  CRESCO clusters using the SLURM framework:  Batch Jobs / SLURM.  This is not a tutorial about using LAMMPS; for that, you may find  documentation, the manual, tutorials, and books on the official website  www.lammps.org/.

Job submission on CRESCO8

To submit LAMMPS on CRESCO8, there are three possible options: lammps/2024_serial and lammps/2024_mpi for the cresco8_cpu partition, and lammps/2024_gpu for the cresco8_gpu partition.

To use lammps/2024_serial and lammps/2024_mpi, login at one of the two front-ends (cresco8x001.portici.enea.it or cresco8x002.portici.enea.it) and load the following base modules:

 1) pfs
 2) base
 3) slurm_tools
 4) intel/oneapi
 5) mpi_flavour/impi-oneapi

lammps/2024_serial

Load the corresponding module:

module load lammps/2024_serial

Then launch a batch job using a SLURM script with the command:

sbatch script_serial.sh

where, for example, script_serial.sh is:

#!/bin/bash
#SBATCH --job-name=nome_job
#SBATCH --err=%j.err                 # standard error file
#SBATCH --out=%j.out                 # standard output file
#SBATCH --time=24:00:00              # time limit
#SBATCH --nodes=1                    # number of nodes
#SBATCH --ntasks-per-node=1          # number of tasks per node
#SBATCH --cpus-per-task=1            # number of threads per node
#SBATCH --partition=cresco8_cpu      # partition name
#SBATCH --account=enea
#SBATCH --auks=yes
#SBATCH --exclusive

aklog

lmp -in file_input.in + "lammps_options"

lammps/2024_mpi

Load the corresponding module:

module load lammps/2024_mpi

Then launch a batch job using a SLURM script with the command:

sbatch script_mpi.sh

where, for example, script_mpi.sh is:

#!/bin/bash
#SBATCH --job-name=nome_job
#SBATCH --err=%j.err                 # standard error file
#SBATCH --out=%j.out                 # standard output file
#SBATCH --time=24:00:00              # time limit
#SBATCH --nodes=1                    # number of nodes
#SBATCH --ntasks-per-node=4          # number of tasks per node
#SBATCH --cpus-per-task=4            # number of threads per node
#SBATCH --partition=cresco8_cpu      # partition name
#SBATCH --account=enea
#SBATCH --auks=yes
#SBATCH --exclusive

aklog

export OMP_NUM_THREADS=$SLURM_CPUS_PER_TASK

mpirun lmp -in file_input.in + "lammps_options"

lammps/2024_gpu

To use lammps/2024_gpu, login at the front-end cresco8-gpu01 and load the following modules:

 1) pfs
 2) base
 3) slurm_tools
 4) intel/oneapi2025
 5) mpi_flavour/impi-oneapi2025
 6) lammps/2024_gpu

Then launch a batch job using a SLURM script with the command:

sbatch script_gpu.sh

where, for example, script_gpu.sh is:

#!/bin/bash
#SBATCH --job-name=nome_job
#SBATCH --err=%j.err                 # standard error file
#SBATCH --out=%j.out                 # standard output file
#SBATCH --time=24:00:00              # time limit
#SBATCH --nodes=2                    # number of nodes
#SBATCH --ntasks-per-node=8          # number of tasks per node
#SBATCH --cpus-per-task=16           # number of threads per node
#SBATCH --gres=gpu:8                 # number of gpu per node
#SBATCH --gpus-per-task=1            # number of gpu per task
#SBATCH --partition=cresco8_gpu      # partition name
#SBATCH --account=enea
#SBATCH --auks=yes
#SBATCH --exclusive

aklog

export OMP_NUM_THREADS=$SLURM_CPUS_PER_TASK

mpirun lmp -in file_input.in + "lammps_options"

ENEAGRID/CRESCO utilization rules

Please check the ENEAGRID/CRESCO conditions of access and how to cite LAMMPS.
